78 Way D Type Plug Connector - Solder Pin

Part number: 204508-1
Manufacturer: TE Connectivity / AMP
Series: AMPLIMITE Series 90
Type: High-density D-Sub receptacle
Positions: 78-way / 78-pin
Gender: Female
Configuration: 4 rows
Termination: Crimp
Mounting: Panel mount
Shell: Steel, cadmium-plated
Contact size: Size 22
Pitch: 2.29 mm (0.09")
Current rating: 5 A maximum
Sealing: Non-sealed
Operating temperature: −55°C to +125°C
Application: High-density signal and cable-to-cable connections
Brief description: 78-pin high-density female D-Sub receptacle from the TE Connectivity AMPLIMITE Series 90, with a metal shell and crimp contacts for panel-mounted signal applications.

SKU: 7-19955

Volume Discounts

Min. Qty	Price
1+ units	£ 18.38
10+ units	£ 17.46
25+ units	£ 17.00
50+ units	£ 16.54
100+ units	£ 16.08

£ 18.38

£ 0.00

Add to cart

Terms and Conditions
UK shipping £6.50 next day delivery as standard.
Our shop is currently for UK-based orders only. For international shipping please contact us for a quote.
